Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
181
Call up the command with the following parameters:
no map protocol
{ip | novell | netbios | appletalk | other <aa:aa>}
enet-v2
The parameters have the following meaning:
Novell Netware protocol
Other protocol. enter the hexadecimal protocol
value.
• other: aa:aa
• IPV6:
86:DD
• LLDP:
88:CC
• PTP IEEE1588:
88:F7
• EAP (802.1X):
Frame structure is Ethernet II
The protocol is removed from all protocol groups.
You create the protocol group with the map protocol command.
You can display the status of this function and other information with the
show vlan
protocols-group
command.
protocol-vlan
Description
With this command, you enable the protocol-based classification on all interfaces.
You are in the Global Configuration mode.
The command prompt is as follows:
cli(config)#
