Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
804 Configuration Manual, 11/2015, C79000-G8976-C252-10
If you do not select any parameters from the parameter list, the default value (both) is used.
Note
VLAN and ACL mirroring
Tx mirroring is not supported with VLAN or ACL mirroring.
As soon as you have configured the settings for the port to be monitored and the destination
port, the session is complete and active.
You delete the source for mirroring a port with the no monitor session ... source command.
You end and delete a session with the
no monitor session command.
You display the configuration settings with the
show monitor session command.
no monitor session source
Description
With this command, you delete the source for mirroring a port or a VLAN.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
