Load control
10.5 Service classes
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
673
Call up the command with the following parameters:
dscp-map <dscp (0-63)> queue <queue(1-8)>
The parameters have the following meaning:
Keyword for a queue -
Queue that is assigned to this DSCP
1 … 8
The DSCP codes are assigned to the queues as follows:
DSCP codes 0 - 7 → Queue 2
DSCP codes 8 - 15 → Queue 1
DSCP codes 16 - 23 → Queue 3
DSCP codes 24 - 31 → Queue 4
DSCP codes 32 - 39 → Queue 5
DSCP codes 40 - 47 → Queue 6
DSCP codes 48 - 55 → Queue 7
DSCP codes 56 - 63 → Queue 8
The assignment table for DSCP codes is configured.
qos-trust-mode
Description
With this command you can set the method according to which packets to be forwarded are
prioritized port by port.
You are in the QOS configuration mode.
The command prompt is as follows:
cli(config-qos)#
