SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
439
This part contains the sections that describe the following:
● OSPFv2 (IPv4)
● OSPFv3 (IPv6)
● RIPv2 (IPv4)
● RIPng (IPv6)
● VRRP (IPv4)
● VRRPv3 (IPv4/IPv6)
The layer 3 functions describe the routing properties of the device. These are not normally
included in the basic device and if necessary must be enabled or released extra.
This section describes commands with which you display various settings.
show ip protocol
Description
This command shows the current settings of the activated routing protocols.
Note
This command is available only with layer 3.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call the command without parameter assignment:
show ip protocol
